Schneider ATV71HU55N4 5.5kW Hız Kontrol Cihazı
28.175,00 ₺
28.175,00 TL den başlayan taksitlerle!
Taksit Seçenekleri
Stok Kodu
1X76Z6A2F7
Fiyat
479,17 USD + KDV
Siparişleriniz en geç 2 iş günü içinde kargoya verilir.
Schneider ATV71HU55N4 5.5kW Hız Kontrol Cihazı
| range of product |
Altivar 71
|
|
|---|---|---|
| product or component type |
Variable speed drive
|
|
| product specific application |
Complex, high-power machines
|
|
| component name |
ATV71
|
|
| motor power kW |
5.5 kW, 3 phases at 380…480 V
|
|
| motor power hp |
7.5 hp, 3 phases at 380…480 V
|
|
| maximum motor cable length |
50 m shielded cable
100 m unshielded cable |
|
| power supply voltage |
380…480 V – 15…10 %
|
|
| network number of phases |
3 phases
|
|
| line current |
17 A for 480 V 3 phases 5.5 kW / 7.5 hp
20.3 A for 380 V 3 phases 5.5 kW / 7.5 hp |
|
| EMC filter |
Integrated
|
|
| assembly style |
With heat sink
|
|
| apparent power |
13.4 kVA at 380 V 3 phases 5.5 kW / 7.5 hp
|
|
| prospective line Isc |
22 kA for 3 phases
|
|
| nominal output current |
11 A at 4 kHz 460 V 3 phases 5.5 kW / 7.5 hp
14.3 A at 4 kHz 380 V 3 phases 5.5 kW / 7.5 hp |
|
| maximum transient current |
21.5 A for 60 s 3 phases 5.5 kW / 7.5 hp
23.6 A for 2 s 3 phases 5.5 kW / 7.5 hp |
|
| Output frequency |
0.1…599 Hz
|
|
| nominal switching frequency |
4 kHz
|
|
| switching frequency |
1…16 kHz adjustable
4…16 kHz with derating factor |
|
| asynchronous motor control profile |
Sensorless flux vector control (SFVC) (voltage or current vector)
Voltage/frequency ratio (2 or 5 points) ENA (Energy adaptation) system for unbalanced loads Flux vector control (FVC) with sensor (current vector) |
|
| type of polarization |
No impedance for Modbus
|
